MADE IN FRANCE!
Focal 300 ICW8
Focal 300 ICW8 predstavlja premium ugradni zvučnik iz Focal 300 Series linije, razvijen za visokokvalitetne stereo i home cinema instalacije. Zahvaljujući mogućnosti montaže u plafon ili zid, model 300 ICW8 omogućava diskretno uklapanje u enterijer bez kompromisa po pitanju zvuka.
Ovaj 2-sistemski koaksijalni zvučnik koristi veliki 8-inčni (21 cm) mid/bass drajver sa ekskluzivnom Focal Flax membranom, dok je za visoke tonove zadužen aluminijumsko-magnezijumski inverted dome tweeter. Flax tehnologija, razvijena i proizvedena u Francuskoj, poznata je po kombinaciji male mase, velike krutosti i odličnog prigušenja, što omogućava veoma prirodan, detaljan i precizan zvuk.
Focal 300 ICW8 karakteriše:
veoma širok frekventni opseg,
odlična dinamika,
visok nivo detalja,
i impresivno dubok bas za ugradni zvučnik.
Tweeter je podesiv i rotirajući, što omogućava optimizaciju visokih tonova prema poziciji slušanja i akustici prostorije. Ugrađena je i regulacija nivoa visokih tonova za dodatno prilagođavanje zvuka prostoru.
300 Series koristi patentirani EQI (Easy Quick Install) sistem montaže koji omogućava veoma jednostavnu i brzu instalaciju bez alata. Magnetne grille bez vidljivog rama mogu se farbati i dostupne su u okrugloj i kvadratnoj varijanti kako bi se zvučnik maksimalno uklopio u enterijer.
Zahvaljujući visokoj efikasnosti i velikoj snazi, Focal 300 ICW8 podjednako je pogodan za:
premium stereo sisteme,
Dolby Atmos i home cinema instalacije,
multiroom audio,
kao i luksuzne rezidencijalne projekte.
Tehničke karakteristike:
Tip: 2-way coaxial in-wall / in-ceiling zvučnik
Mid/Bass: 8" (21 cm) Flax drajver
Tweeter: 1" aluminijumsko-magnezijumski inverted dome
Frekventni opseg (+/-3 dB): 48 Hz – 28 kHz
Donja granična frekvencija (-6 dB): 35 Hz
Osetljivost: 90 dB
Nominalna impedansa: 8 Ω
Minimalna impedansa: 4.5 Ω
Preporučena snaga pojačala: 25 – 150 W
Prečnik zvučnika: 299 mm
Ugradni otvor: 264 mm
Dubina ugradnje: 122 mm
Magnetna grille bez rama
Mogućnost farbanja grille.
How to install 300 Series 300IWLCR6 & 300IW6 integration loudspeakers ?
How to install 300 Series in-wall and in-ceiling loudspeakers
INNOVATIONS FOCAL
The exclusive Flax membrane technology uses an eco-textile based on French flax fiber. The stiffness and lightness of these cones deliver remarkably neutral, well-defined sound. The adjustable and directional tweeter, meanwhile, enables the treble to be adjusted to the room's acoustics.
DOLBY ATMOS® TECHNOLOGY
In addition to stereo and surround applications, 300 ICW8 adapts perfectly to Dolby Atmos® technology, adding a vertical sound dimension. Immersive and powerful, this 3D sound is ideal for watching movies or playing video games, as if you were right in the heart of the action.
FOCAL SOUND MAKES THE INVISIBLE VISIBLE
EASY INTEGRATION
Thanks to the EQI (Easy Quick Install) mounting system, no tools or screws are required, making installation quick and easy! Round or square, the grilles are magnetized and designed to be painted to blend in perfectly with any interior.
SPECIFICATIONS
Sound - Acoustics
Product type : 2-way
Membrane :
Flax
Medium : 8" (21cm) Flax Mid-bass
Response at - 6dB (Low frequency point) : 35 Hz
Frequency response (+/- 3dB) :
48 Hz - 28 kHz
Minimum impedance : 4.5 Ω
Nominal Impedance : 8 Ω
Recommened amplifier power : 25 - 150 W
Sensivity : 90 dB
Design
Allowable ceiling thickness (min) : 5 mm / 0.1875 in
Allowable ceiling thickness (max) : 30 mm / 1.19 in
Easy Quick Install : Yes
Depth behind surface (Mounting depth) : 4.8 in / 4.8 in
Cut-Out diameter : 264 mm / 10.39 in
Depth : 299 mm / 11.76 in
Accessories
Black and white felt : Black and white felt ready to stick
Cut Out template : Yes
Grids : Delivered with ready-to-paint square and circular front grilles and painting protective mask
